The extinguisher agent in Grap Fire Clean Agent Fire Extinguisher is HFC 236 fa, HEXAFLOUROPROPANE which is electrically non conductive, non - corrosive, environmental friendly and free residue " hence is a best replacement of HALON 1211. Fire Extinguisher agent in GraP Fire Clean Agent Fire Extinguisher is in liquid form & when comes in contact with air turns in to gas form. It is effective on class A, B & C fires & it. Gra p fire Clean Agent Fire Extinguisher / Automatic are available in capacities of To Kg., 5 Kg and as per requirement. used in several available at reasonable prices for the client requirement.
Capacity (Ltr.) | 2 | 4 | 6 |
Anti-Corrosive Inhibitor | Epoxy Polyester coating | Epoxy Polyester coating | Epoxy Polyester coating |
Confirming IS code | 15683 | 15683 | 15683 |
Type of Extinguisher | Constant Pressure | Constant Pressure | Constant Pressure |
Type of Extinguisher Media | HFC 236 fa | HFC 236 fa | HFC 236 fa |
wxpellant | Pressurized with N2 gas | Pressurized with N2 gas | Pressurized with N2 gas |
Minimum Effective Discharge (%) | 95 | 95 | 95 |
Minimum Jet Length (mtrs.) | More than 2 mtrs. | More than 2 mtrs. | More than 2 mtrs. |
Discharge time (Sec.) | More than 13 Sec. | More than 13 Sec. | More than 13 Sec. |
Hydraulic Test Pressure (Kgf/cm2) | 35 | 35 | 35 |
Operation Position | Upright | Upright | Upright |
Charged Pressure (Kgf/cm2) | 18 | 18 | 18 |
Operating Temperature Range ( 0C) | 0 to (+)55 | 0 to (+)55 | 0 to (+)55 |
Operating value | Squeeze Grip Type with Nozzle | Squeeze Grip Type with Discharge hose and Nozzle | Squeeze Grip Type with Discharge hose and Nozzle |
Fire Rating | 1A,8B,C | 2A,13B,C | 3A,21B,C |
